Plasma Generation Power Source |
|
| It is test equipment for the 3-phase synthetic making test of circuit breaker of distribution system according to circuit breaker standards (IEC62271-100) |
|
|
|
Ratings |
|
|
| Installation Type |
Portable type Mounted on a trolley |
| Control Unit Control Voltage |
AC 220V |
| Insulation Type |
Operating Pressure: 0.5~3MPa(Gauge)
High pressure air injection type Washing Pressure: 7MPa(Gauge) |
| Rated Insulation Voltage |
Between electrodes 200kVac
Electrode to ground 400kVac, 550kVdc |
| Carrying Current |
Between main electrodes: 63kA(rms), 165kAp(Peak), 60ms
Input/output conductor: 63kA(rms), 165kAp(Peak), 0.5sec |
| Main Electrode Material |
(High strength) Graphite |
|
|
|
|
